Jul. 20, 2023
Classification of HOPU transformer oil purifier machine
Transformer oil purifier machine are mainly divided into two categories: single-stage vacuum transformer oil purifier and two-stage high-efficiency vacuum transformer oil purifier machine.
The transformer oil filter can quickly remove harmful components such as moisture, gases, and impurities from the transformer oil, improve the lubrication performance of the transformer oil, reduce rust or corrosion of the oil equipment due to excessive moisture or impurity content, and extend the service life of the oil equipment.
The equipment for filtering transformer oil mainly includes: ultra-high voltage transformer oil purifier, two-stage vacuum transformer oil purifier, high-efficiency vacuum oil purifier, plate and frame type oil filter, cart type oil filter, on-load switch online oil filtration machine, and insulation oil regeneration device.
1.The use of ultra-high voltage transformer oil purifier is relatively rare, mainly used for ultra-high voltage transformer oil filtration, and used by large power plants and power companies.
2. two-stage vacuum transformer oil purifier is mainly used for filtering transformer oil above 110KV, for maintenance of transformer customers, and is commonly used in power plants.
3. High Efficient vacuum oil purifier, also known as single stage vacuum transformer oil filter, can be used for small transformer oil filtration. For transformer oil below 110KV, it is suitable for use in small substations.
4. Plate and frame oil filters are widely used, mainly for removing mechanical impurities in oil, which can remove a small amount of water in the oil, but their functions are limited.
5. Portable oil filter adopts a filter element for filtration, mainly used to remove mechanical impurities in the oil, and cannot be dehydrated. Its function is limited.
6. On load switch online oil filtration machine is used for oil filtration on the transformer's on load switch.
Characteristics of HOPU single stage transformer oil vacuum oil purifier
It is a specialized equipment used in power plants, power stations, power companies, metallurgical, petrochemical, railway and other industrial and mining enterprises to purify and treat unqualified electrical insulation oil. It can also be used for vacuum injection and extraction of insulation power equipment, vacuum drying of electrical equipment moisture.
1. Three dimensional flash evaporation, efficient dehydration and degassing.
2. A impurity removal technology combining mesh filtration and polymer adsorption.
3. Infrared liquid level automatic control.
4. Trinity interlocking and protection device.
5. This machine can be used independently or in conjunction with an oil regeneration system.
6. This machine can vacuum oil and dry insulated power equipment such as transformers.
7. It can randomly test the withstand voltage value and automatically print the test results (usually a purchase option).
8. This machine can be used together with a transformer oil regeneration and decolorization device to add functions such as acid removal, decolorization, free carbon removal, and dielectric loss reduction (commonly known as a multifunctional insulation oil filter).
9. This machine has both vacuum oiling and live online operation functions.
This machine has a three in one interlocking electrical automatic protection device (phase sequence protection, overload protection, overvoltage protection), using our company's specially designed precision oil pump, low noise, and meets the high standards of environmental protection in the world.
Characteristics of HOPU Double Stage Vacuum Transformer Oil Purification Machine
1. Mainly used for on-site maintenance of large transmission and transformation voltage equipment above 110KV and national main transformer power grids, as well as for rapid and deep treatment of insulation oils such as new oil and imported oil in large substations, as well as vacuum filtration and purification treatment of more expensive heavy oils such as new oil, imported oil, transformer oil, and transformer system capacitor oil and refrigeration oil.
2. The various indicators of the product are significantly higher than national standards. Compared with single stage vacuum oil filters, their dehydration, degassing, and impurity removal (mechanical impurities and free carbon) effects are faster and more thorough. The oil limit withstand voltage and flash point are higher, and the breakdown voltage can be increased by 35KV in one filtration, reducing the harm of oil aging caused by multiple heating in general oil filters.
3. The two-stage vacuum with high pumping rate can greatly improve the vacuum environment inside the tank, achieving high vacuum. The ultimate vacuum is ≤ 5Pa, and the working vacuum is ≤ 35Pa, keeping the oil temperature unchanged during the treatment process, meeting the needs of vacuum pumping for the transformer body on installation or maintenance sites, and greatly shortening the oil treatment period.
4. A unique degassing and dehydration system, with a duplex three-dimensional flash evaporation, can quickly remove liquid water. Using UK microgram technology, it can effectively remove trace amounts of water such as dissolved water, efficiently complete degassing, dehydration, and treatment of transformer oil, improve the insulation strength and oil content of the oil
